Liquid Flow Meter Selection Site

Simply enter your application information below and a product expert will email you a recommended parts list.

*Only supported within the United States

STEP1What type of liquid?

Liquids only (ex. Water, coolant, oil, adhesive, grease, etc.), no gases or air.

If considering multiple flow applications, please submit each application separately.

STEP2What are the pipe characteristics?

Pipe Material

Examples: Stainless steel, PVC, copper, plastic tube, etc.

Undecided

Please note our flow meters are only designed for single material pipes/tubes. They are not compatible with lined pipes or braided hosing.

Pipe Size

Nominal Pipe Size (NPS)	in
Outer Diameter (OD)

Undecided

Please enter both OD and NPS pipe size if possible. You can click the button below to see a Pipe Size Reference Chart.

Pipe Size Reference Chart

NPS	OD [mm in]
N/A	3.18mm - 10.29mm 0.125"- 0.405"
1/8	10.29mm 0.405"
1/4	13.72mm 0.540"
3/8	17.15mm 0.675"
1/2	21.34mm 0.840"
3/4	26.67mm 1.050"
1	33.40mm 1.315"
1 1/4	42.16mm 1.660"
1 1/2	48.26mm 1.900"
2	60.33mm 2.375"
2 1/2	73.03mm 2.875"
3	88.90mm 3.500"
3 1/2	101.60mm 4.000"
4	114.30mm 4.500"
4 1/2	127.00mm 5.000"
5	141.30mm 5.563"
6	168.28mm 6.625"
7	193.68mm 7.625"
8	219.08mm 8.625"

STEP3What is the fluid temperature?

For fluids with large temperature changes, please input as a range.
Example: 0-80 ° C

STEP4What do you want to monitor?

Instantaneous Flow Rate - Monitor the current rate of liquid flow
Accumulated (Total) Amount - Measure the total amount of liquid that has passed
Shot/Dispensing Amount - Measure the amount of liquid dispensed for single or multiple shots
Other

What will the flow rate be?

Unsure

For fluids with large flow rate fluctuations, please input as a range.
Example: 10-200 Gallons per Minute

What will the shot amount be?

Unsure

What will be the length of time of the shot?

Unsure

STEP6Please provide any other relevant application details.
(Optional)

Example: Machine type and location, process info, etc.
